| Product marketing name | HUAWEI MateBook 14 |
| Product model | KLVF-X |
| Configuration | KelvinF-W5651T |
| External name | HUAWEI MateBook 14 |
| TTM | June 2022 |
| Color | Mystic Silver, Space Gray |
| Materials | Aluminum alloy (Shells A, C, and D are made of aluminum alloy and surface B is the glass top panel.) |
| Rotation angle | 150° |
| One-Hande Opening | Not Supported |
| Screen-To-Body Ratio | 90% |
| Narrow Bezel | 4.9mm (left/right/top) |
| Body dimensions | 307.5 mm(H) * 223.8 mm(W) * 15.9 mm(D) Remarks: The actual dimensions may vary depending on the configurations, manufacturing process, and measurement method. |
| Thickness (mm) | 15.9mm Remarks: The actual dimensions may vary depending on the configurations, manufacturing process, and measurement method. |
| Package dimensions | 473 mm(H) * 280 mm(W) * 68 mm(D) Remarks: The actual dimensions may vary depending on the configurations, manufacturing process, and measurement method. |
| Main body weight | Approx. 1.49 kg (including battery) Remarks: The actual weight may vary depending on the configurations, manufacturing process, and measurement method. |
| Weight with package | Approx. 2.0 kg Remarks: The actual weight may vary depending on the configurations, manufacturing process, and measurement method. |
| Operating System | Windows 11 Home 64-bit |
| AI Processor | Not Supported |
| Number of CPU cores | 12 cores: 4 performance cores + 8 efficient cores |
| CPU model | 12th generation Intel® Core™ i5-1240P processor |
| CPU frequency | P-core: Base1.7GHz, Up to 4.4GHz;E-core: Base1.2GHz, Up to 3.3GHz; |
| CPU Threads | |
| Integrated Graphics GPU | Intel® Iris® Xe Graphics |
| dedicated Graphics Model | Not Supported |
| dedicated Graphics Frequency | Not Supported |
| dedicated Graphics styles | Shared System Memory |
| dedicated Graphics Memory | Shared System Memory |
| dedicated Replaceable | Not Supported |
| Graphics Expansion | Not Supported |
| dedicated Graphics GPU bit | Shared System Memory |
| Graphics Model | Integrated Graphics |
| Double Graphics | Not Supported |
| Memory Type（RAM） | LPDDR4x |
| Memory Replaceable（RAM） | Not Supported |
| Memory Expansion（RAM） | Not Supported |
| Memory Category（RAM） | Chip on board |
| Memory Channels（RAM） | Dual Channel |
| Memory Capacity（RAM） | 16GB |
| Memory max Capacity | 16GB |
| Memory frequency（RAM） | |
| Storage Replaceable | SSD: Supported |
| Extended storage card type | Not Supported |
| Storage Expansion | SSD: Not Supported |
| Hard disk type | SSD |
| SSD | Supported |
| SSD Protocol | NVMe |
| SSD status | M.2 2280 |
| Theoretical transmission rate of SSD interfaces | PCIE3.0 x 4: 32 Gbit/s |
| SSD capacity | 512GB |
| HDD capacity | Not Supported |
| LCD contrast ratio | 1500:1 (typical value) |
| LCD viewing angle | 178° (typical value) |
| LCD size | 14 inch |
| LCD resolution | 2160*1440 |
| LCD screen PPI | 185 |
| Brightness | 300 nits (typical value) |
| Eye Comfort Mode | Supported |
| Touchscreen hardware specifications | Supported(10-point touch, Anti-fingerprint) |
| LCD screen type | IPS |
| LCD screen color | 100% sRGB(Typical) |
| Environmental light sensor | Not Supported |
| Screen ratio | 3:2 |
| Bluetooth version | Bluetooth5.1 |
| WLAN frequency band | 2.4GHz and 5GHz |
| WLAN protocol | IEEE 802.11a/b/g/n/ac/ax,160MHz |
| WLAN antenna | 2x2 MIMO |
| WLAN encryption mode | WPA/WPA2/WPA3 |
| Theoretical WLAN rate | 2.4 Gbit/s (maximum rate) |
| NFC | Not Supported |
| GPS Vendor | Not Supported |
| USB-C Port Function | (First) USB-C port on the left, supporting USB3.2 Gen 1 (charging, display, and data transmission) (First) USB-A port on the right, supporting data (USB 3.2 Gen1) and external power supply of 10 W (5 V and 2 A) (Second) USB-A port on the right, supporting data (USB 3.2 Gen1) and external power supply of 10 W (5 V and 2 A) |
| Thunderbolt Port | Not Supported |
| Display Interface | Not Supported |
| Audio Port | 3.5mm headset and microphone 2-in-1 jack *1 support both OMTP and CTIA |
| Other Buttons and interfaces | |
| Number of speakers | Speaker * 2 |
| Speaker Effects | Immersive surround sound |
| Speaker Power | 2 W * 2 (rated power) |
| Number Of Microphone | Microphone * 4 |
| Front camera type | Recessed camera |
| Front camera pixel | 720P HD camera Video Recording / Video Chat |
| Front camera indicator | Supported |
| Front camera flash | Not Supported |
| Front camera infrared | Not Supported |
| Front camera recording/video chat | Supported |
| Facial recognition by front camera | Not Supported |
| Hall sensor | Supported |
| Gravity sensor | Not Supported |
| Gyroscope | Not Supported |
| Other Sensors | Not Supported |
| Touchpad hardware specifications | Support 5-point multi-touch(Window 11 supports 4 point only) |
| Material of the touchpad top cover | Mylar |
| Touchpad size | 120.2 mm * 72.2 mm |
| Power Button | Fingerprint power button |
| Keyboard type | Full-size keyboard |
| Keyboard backlight | Supported |
| Keyboard anti-splashing | Not Supported |
| Travel distance | 1.3 mm |
| Numeric keypad | Not Supported |
| Huawei Share OneHop | Supported |
| Default browser | Microsoft Edge |
| Local Update | Using USB flash disk |
| System recovery | Supported |
| Online Update | Support online update by windows update Support updating drivers using Huawei PC Manager |
| Unique applications | Super Device/Huawei PC Manager/ Display Manager (Eye Comfort Mode)/Huawei factory reset/Link Now |
| Input method | Microsoft input method |
| Adapter specifications | 65 W USB-C power adapter (standard) Input: 100 V–240 V AC, 50 Hz/60 Hz Output: 5 V/2 A; 9 V/2 A; 12 V/2 A; 15 V/3 A; 20 V/3.25 A Weight: Approx. 137 g(without cable) Length of power adapter cable: 1.8 m Weight of power adapter cable: Approx. 43 g |
| Keyboard holster | Not Supported |
| Conversion cable | Not Supported |
| Docking station | HUAWEI MateDock 2 (Optional) HUAWEI MateDock 3 (Optional) |
| Bluetooth mouse | HUAWEI Bluetooth Mouse(optional) |
| Stylus | Not Supported |
| Backpack | Optional |
| Laptop sleeve | Optional |
| Other standard accessories (standard) | Not Supported |
| Film | Not Supported |
| Battery capacity | 56Wh(Rated capacity)(7330mAh*7.64V) |
| Battery type | Li-polymer |
| Replaceable battery | Not Supported |
| Theoretical charging time | It takes 30 minutes to charge 40% of the battery, 60 minutes to charge 74% of the battery, and 100 minutes to charge the battery full. Remarks: 1. The above data is laboratory data obtained by using a standard adapter for screen-off charging. The actual battery charging time varies depending on the actual situation. 2. Test conditions: The standard dedicated charger is used, and the system maintains the power-off state. |
| Charging indicator | Supported (White flashing indicates charging and white steady-on indicates fully charged.) |
| Power indicator | Not Supported |
| Battery life | It takes about 8 hours to play a local 1080p video. Remarks: Laboratory tests show that the playback time of a local 1080p video will vary with laptop configurations under the brightness of 150 nits. |
| China Energy Level | First Level |
| Temperature range for charging or discharging | 0°C~ 40°C (32°F~104°F) |
| Working environment humidity | 5%~95%,Non-condensing |
| Standard packing list | 1. PC * 1 2. USB-C power adapter * 1 3. Power adapter cable (USB-C) * 1 4. Quick start * 1 5. Warranty card * 1 |
| Application scenario | |
| Number of battery cores | |
| Storage temperature | |
| Product type | |
| WIFI chip factory | |
| LCD refresh rate | |
| EVO | Not supported |
